Easy Storage Management with 2 Bays RAID System for 3.5" SATA HD via Super Speed USB3.0 up to 5 Gbps
|
|
-
Supports 3,5" SATA-III ( 6Gbps) & SATA-II (3Gbps) & SATA-I (1.5 Gbps) compliant HDDs
-
Supports 2x SATA HDD up to 4TB / RAID 0 Stripping/ RAID 1 Mirroring / JBOD
-
Provides Striping (RAID 0), Spanning, Mirroring (RAID 1) and JBOD RAID Modes
-
OTB file data backup by one hot key touch
-
Support USB 3.0 Super Speed (5Gbps), High Speed (USB2.0 ) and Full Speed (1.2 Mbps) transfer.
-
Aluminium Housing and temperature control fan to achieve best cooling for the HDD's
-
Supports automatic rebuild in Mirroring mode
-
Communicates system status via LED indicators
-
Dissipates heat effectively w/ aluminium housing
-
Maximum airflow with quiet, high output fan
-
Supports hot-plug and HDD hot-swap
-
Auto Shut-down HDD within 3 minutes without data transfer
|
|
|
Model |
U350SR-U3 |
|
|
Interface |
eSATA / USB2.0 |
|
|
HDD Support |
3,5" SATA HDD ( identical HDD recommended ) |
|
|
RAID Level |
Striping ( RAID 0 ) |
|
|
|
Spanning ( RAID 1 ) |
|
|
|
JBOD |
|
|
Data Transfer Speed |
eSATA : up to 3000 Mb/sec |
|
|
|
USB2.0 : up to 480 Mb/sec |
|
|
LED Indicators |
Power ON / Power OFF / Access / Rebuild / Error |
|
|
Power Supply |
Input : AC90-264 V |
|
|
|
Output : DC+12V/2A, +5V / 2A |
|
|
Dimension |
220 x 85 x 130 mm |
|
|
|
|
|
|
Package include |
2 Byas RAID system |
|
|
|
USB Cable |
|
|
|
installation CD |
|
|
|
AC Adapter |
|
|
|
Manual for RAID
|
|
|
|
|
|
|
System Requirements |
PC: 266 MHz or faster CPU ( 800 MHz for Window Vista) |
|
|
|
64MB RAM ( 512 MB RMA for Windows Vista ) |
|
|
|
Microsoft Windows 2000, XP, Window Vista |
|
|
|
Mac OS 10.2 or higher / Mac OS X 10.4 ( Intel Core Duo) |
|
|
|
64 MB of RAM ( 256MB for Mac OS X10.4 ) |
|
